Ehrgeiz Fusion 2 RGBW 20x15W LED

Description

Features

• 20x15W RGBW LEDs
• 6° optics
• Fanless outdoor system
• Seamless connection system
• Various beam angles thanks to diffuser filters
• Vertical stand and hanging installation
• Wide range of colours
• Consistent mixed colours, even when brightness changes
• Uniform colour rendering
• RGBW, 8 or 16 bit resolution
• Continuously variable CTO
• Virtual colour wheel with 39 colours including white
• Each LED can be controlled individually in any colour
• Pattern effect with variable speed
• High-resolution dimmer 0-100%
• Selectable dimming curves
• Strobe with variable speed (max. 20Hz)
• Pre-programmed random strobe and pulse effects

Technical specifications

• LEDs: 20x15W RGB
• Lifespan: approx. 20,000 hours
• Optical system: ConstantColor™ Optics
• Beam angle: 6°
• Max. ambient temperature: 45°C
• Cooling: Convection cooling
• Protocol: USITT DMX-512
• DMX control modes: 8
• Stand-alone mode
• DMX in/out: 5-pin XLR
• Power in/out: Neutrik powerCON TRUE 1
• Power connection: Electronic switching power supply with automatic detection
• Input voltage: 100-240V, 50/60Hz
• Max. power consumption: 330W
• Protection class: IP65
• Dimensions with stand (WxDxH): 1006x90x231mm
• Dimensions without stand (WxDxH): 1006x90x181mm
• Weight: 12.5kg
