Description
Technical Specifications:
KNV Light Source:
1 x 30 W Hyper White + 16 x 0.5 W RGB
Number of Power Pixels: 5
Controls & Programming:
Control Modes: Normal / Compressed / Pixel Mapping
Protocol(s): DMX (USITT DMX512-A) / RDM (ANSI/ESTA E1.20) / Art-Net: sACN
Setup and Addressing: backlit graphic display / DMX / RDM
Display: illuminated graphic LCD / self-charging backup battery / illuminated buttons
Cooling: temperature-controlled / overheating protection
Software Update: DMX Link
Dimmer Curves: linear / soft
Fan Modes: regulated / high / medium / low
Connections:
Signal connection: 5-pin XLR / etherCON / In/Out
; Power connection: Neutrik powerCON TRUE1 / In/Out
Operating parameters:
Mains voltage: 100–240 VAC / 50–60 Hz
Power (watts @ 230 V): 170 W max.
Ambient temperature: 40°C / 104°F
Protection class: IP 54
