Description

Technical data :

MX-DVI-FR16 is a high performing modular expandable DVI 1.0 and HDMI 1.3 compliant matrix switcher that offers up to 16 Input and up to 16 Output.
The built-in sophisticated software and hardware features make the router a flexible and integrated solution for AV professionals and high-end home theatre applications.

• EDID memory: 50 factory preset and 50 user programmable
• EDID emulation: 256-Byte Extended EDID v1.3
• Front panel buttons: Yes
• Front panel LCD: Yes
• RS-232/422: 9600 Baud RX, TX
• LAN: Ethernet 10Base-T or 100Base-TX (Auto-sensing)
• EMI/EMC compliance: Yes, EN 55022 Class B
• RoHS compliance: Yes
• Dimensions with rack mounting ears: 482 W x 176,5 H x 300 D mm
• Dimensions without rack mounting ears: 440 W x 176,5 H x 300 D mm
• Net weight : 21.6 lbs / 9,8 kg
• Power consumption2: 12 W
• Number of power supplies: 1
• Power supply hot swappable: No
• Cooling: forced convection, 2 pcs. 119 x 119 x 25 mm fans
